| Zahlungsart: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW |
| Minimum der Bestellmenge: | 1 Roll |
| Transport: | Ocean,Land,Air,Express |
| Hafen: | TIANJIN ,QINGDAO |
Marke: Ruili
Herkunftsort: China
Material: Eisendraht, Stahldraht, Galvanized Iron Wire
Oberflächenbehandlung: Verzinkt, PVC beschichtet
Spezies: Stacheldrahtspule, Stacheldrahtgeflecht, Stacheldrahtstrang
Klingentyp: Einzelrasierer, Kreuz Rasiermesser
Modell Num.: BTO-22, BTO-30
Barbed Distance: 4"
Barb Length: 22mm
Coil Outside Diameter: 450mm
Color: Galvanized
Width: 2m Max
Height: 2m
Transport Package: Wooden Case, Gunny Bag
Specification: BTO18 BTO22, BTO28, CBT65
Trademark: RUILI
Origin: Anping, Hebei
HS-Code: 73130000
Produktionskapazität: 100ton/Month
Twist Method: Welded
Anwendung: Protecting Mesh, Fence Mesh
Finish: Hot Dipped Galvanized
Razor Barbed Type: Cross Razor
Wire Gauge: 2.5
| Verkaufseinheiten | : | Roll |
The file is encrypted. Please fill in the following information to continue accessing it
Materialien: Heiß getippt verzinkt, elektro verzinkt, Edelstahl, Eisendraht, PVC-beschichtete Draht
Typ: CBT (Konzertina -Stachelband) und BTO (Hindernis des Stachelbands)
Typ: BTO-10, BTO-12, BTO-15, BTO-18, BTO-22, BTO-30, CBT-60, CBT-65 usw.
Außerhalb von 450 mm, 500 mm, 700 mm, 600 mm, 980 mm, 1000 mm usw., wie Kunden anfordern
[Matrial]
Elektro verzinkter Kerndraht und Klinge
Heiß getippte verzinkte Kerndraht und Klinge
Stahlkerndraht und Klinge
PVC beschichtetes Kerndraht und Klinge
Heiß getippte verzinkte Kerndraht+Edelstahlklinge
Rasiermessertyp: einzelner Typ, Kreuzungstyp (3 oder 5clp pro Kreis)
Stacheldrahtzaun Rasierer
Heiß getippte, verzinkte Zinkbeschichtungsqualität:
| Outside diameter | NO. of loop | Standard Length per Coil | Type | Notes |
| 450mm | 33 | 8m | CBT-60,65 | Single coil |
| 500mm | 41 | 10m | CBT-60,65 | Single coil |
| 700mm | 41 | 10m | CBT-60,65 | Single coil |
| 960mm | 53 | 13m | CBT-60,65 | Single coil |
| 500mm | 102 | 16m | BTO-10,15,22,30 | Cross type |
| 600mm | 86 | 14m | BTO-10,15,22,30 | Cross type |
| 700mm | 72 | 12m | BTO-10,15,22,30 | Cross type |
| 800mm | 64 | 10m | BTO-10,15,22,30 | Cross type |
| 960mm | 52 | 9m | BTO-10,15,22,30 | Cross type |
| Note: The blade types and specifications can be customized according to the customers' actual equirements. BTO-10 and BTO-22 are normally used in production of cross type. | ||||
| High | Standard cover length | Weight |
| 500mm(20inch) | 15M(50ft) | 9.5kg(21lbs) |
| 700mm(28inch) | 15M(50ft) | 13kg(29lbs) |
| 900mm(36inch) | 15M(50ft) | 14.5kg(32lbs) |
| Hole Size | Hole Style | Width | Length | Blade style |
| 100mmX100mm | square or diamond | 1.2m | 2.4m | BTO-10.15.22.30 CBT-60.65 |
| 100mmX150mm | square or diamond | 1.2m | 2.4m | BTO-10.15.22 CBT-60.65 |
| 100mmX200mm | square or diamond | 1.2m | 2.4m | BTO-10.15.22 CBT-60.65 |
| 150mmX300mm | square or diamond | 1.2m | 2.4m | BTO-10.15.22 CBT-60.65 |
| Notes: Any sizes can be customized by customer's request. | ||||
Kabel:
Grad A: Draht 60-80 g/m2 Klinge: 60-80 g/m2
Grad B: Draht 80-120G/M2 Blade: 100-150 g/m2
Grad C: Draht 160-200G/M2 Blade: 230-270 g/m2
Flachdraht
Maschengröße: 75*150,150*300
