ANPING FUHUA WIRE MESH MAKING CO.,LTD
| Zahlungsart: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF,EXW |
| Minimum der Bestellmenge: | 1 Piece/Pieces |
| Transport: | Ocean,Land,Air |
| Hafen: | TIANJIN XINGANG |
Modell Num.: 50x200mm
Origin: China
HS-Code: 73134100
Produktionskapazität: 500PCS/Day
Material: Pvc Coated Steel Wire
Anwendung: Protecting Mesh, Construction Wire Mesh, Decorative Mesh, Fence Mesh
Hole Shape: Square
Transport Package: Pallet
Specification: 2mx2.5m, 2mx3m
Trademark: RUILI
| Verkaufseinheiten | : | Piece/Pieces |
The file is encrypted. Please fill in the following information to continue accessing it
| Specification for welded mesh fence panel | |||||
|
Wire diameter |
Mesh size | Panel width | Panel height | Fold no. | Surface treatment |
| (mm) | (mm) | (mm) | (mm) | ||
|
4.0mm 4.5mm 5.0mm 5.5mm 6.0mm |
50x150mm 50x200mm 55x200mm 60x200mm 65x200mm |
2000mm 2255mm 2500mm 3000mm |
530mm | 2 |
(1)Electro gal. (2)Hot dipped gal. (3)Pvc coated (4)Powder sprayed. (color:green/yellow/ black/white/gray) |
| 630 mm | 2 | ||||
| 830 mm | 2 | ||||
| 1030mm | 2 | ||||
| 1230mm | 2 | ||||
| 1530mm | 3 | ||||
| 1730mm | 3 | ||||
| 1830mm | 4 | ||||
| 2030mm | 4 | ||||
| 2430mm | 4 | ||||
4. Die Oberflächenbehandlung von geschweißtem Netzzaun:
Wir bieten die folgenden Arten von Mesh -Zaunoberflächenbehandlungen, die unterschiedliche Oberflächenbehandlung zur Lebensdauer von| Surface treatment | Min. | Max. |
| Electric galvanizing | 20g/m2 | 60g/m2 |
| Hot dipped galvanizing | 35g/m2 | 400g/m2 |
| Powder painted | 100 microns | 120 microns |
| PVC coating | 400 microns | 600 microns |
5.Der beliebter Beitrag für geschweißtes Netzzaun:
| Post style | Post size | thickness | fitting |
| Square post | 50x50mm | 1.5mm to 2.5mm |
Plastic or metal clips,rain-hat. Bolt and nut. |
| 60x60mm | |||
| 80x80mm | |||
| Rectangle post | 40x60mm | 1.5mm to 2.5mm | |
| 60x80mm | |||
| 60x120mm | |||
| Peach-shape post | 50x70mm | 1.1/1,2/1.5mm | |
| 70x100mm | |||
| Round post |
38mm/40mm/ 42mm/48mm/ 60mm |
1.5mm to 2.0mm |
